Installation Diagram – Down Opposite End Connection
- Hot Water Inlet
- Cold Water Inlet
- Hanger Metal Sheet
- Rawlplug
- Coach Screw
- Back-up Ring
- Blind Flange
- Routing Chock
*Do not use with Cross Connection and Parallel Connection
Montaj Şeması - Çapraz Bağlantı
- Hot Water Inlet
- Cold Water Inlet
- Hanger Metal Sheet
- Rawlplug
- Coach Screw
- Back-up Ring
- Blind Flange
- Routing Chock*
*Do not use with Cross Connection and Parallel Connection
